SPECIFICATION
| Full length |
705mm(effective length;600mm) |
1m〜10ｍ |
| External diameter |
3mm(flexible stainless tube 6mm) |
3.5ｍｍ。4.8ｍｍ |
| Type of imageguide |
Silica imageguide |
Plastics |
| Number of pixels |
6000 |
7400 |
| Premissable bending radius |
70mm |
50ｍｍ |
| Focus range |
5mm〜∞ |
5mm〜∞ |
| Field of view |
approx70° |
approx70° |
| Observing direction |
direct |
direct |
| Temperature |
-20℃〜+80℃ |
-20℃〜+80℃ |
| Weight |
approx0.7Kg |
|
| Accomodating case dimention |
width 370 x depth270 x thickness80mm |
|
● Lamp house
| Type of lamp |
Halogen LED |
| Avarage lifetime of the lamp |
Approx.20 |
| Type of battery |
Lithium battery(CR-123A) |
| Average lifetime of the battery |
Approx, 1 hour of copntinuos use |
●Expanded System
Can be connected to a light source(available at your local distributor)using a LG extension cord.
Monitor observation,video recording can be made by using TV adapter and CCD camera or CCD
camera system.Photography oseing reflex camera is possible.
